75TR3DJ
LG 75″ Interactive Digital Board
Key Features
- Brightness : 390 nit (w/o Glass, Typ.)
- Multi Touch Point : 20 Points (Max.)
- Interface : HDMI (3), RGB (1), Audio In (1), RS-232C In (1), RJ45 (1), USB 3.0 Type A (3), USB 2.0 Type A (3), Audio Out / Optical Output, Touch USB (2)
Contact us
GGEAR Commercial
SMOOTH TOUCH & WRITING EXPERIENCE Multi Touch
The TR3DJ series can simultaneously use up to 20 points of multi touch. This function offers a lifelike board touch experience and makes collaboration much easier.
Enhanced Visibility with Low Parallax
With 1mm gap between the screen and tempered glass, which supports low parallax, The TR3DJ series can offer precise touch and excellent writing experience.
Dual Pen & Dual Color
The stylus pen comes in two different colors and with two different tip sizes of 3mm and 8mm. The dual pens enable users to write or draw simultaneously.
Easy Writing Experience
The TR3DJ series allows you to write and annotate on sources, so your writing experience can be easy and satisfying.
Air Class
Air Class supports connecting up to 30 students and offers interactive meetings for mobile devices on the same network, providing a variety of tools such as voting, answering, and sharing project texts. Air Class is easily accessible from the TR3DJ's main toolbar.
EASY CONNECTION & SHARING Built-in OPS Slot
The TR3DJ series supports OPS* slots, allowing you to easily and conveniently mount an OPS device at the back of the digital board without the hassle of connecting to an external desktop, offering you more expanded functions.
EASY CONNECTION & SHARING ScreenShare Pro
ScreenShare Pro enables you to show up to six shared screens or a file on a screen in real-time, and it has enhanced usability by allowing users to share Chromecast and Apple device mirroring on the same network without any additional application.
Bluetooth Connectivity
TR3DJ supports Bluetooth wireless connections to various devices such as speaker, mouse, keyboard, etc. This is optimal for building a hybrid environment so that online and offline meetings and classes can proceed smoothly.
USER FRIENDLY EXPERIENCE Web Browser
The TR3DJ series supports an embedded Android web browser, so you can search the web easily and quickly, without connecting to an external tablet or computer.
Toolbar
The Toolbar allows you to easily find and run the tool you need. The annotation feature works on virtually all file types, and you can highlight the section you wish to emphasize using the Spotlight function. The countdown and stopwatch features help you manage class time effectively.
USER FRIENDLY EXPERIENCE Audio Experience
The TR3DJ series supports built-in speakers in both sides of the front bezel which deliver clear audio experience.
USB Block
USB Block Mode is a security measure that helps prevent data from being copied to unauthorized devices, which is essential for being used in spaces where security is critical.
Screen Size
75"
Panel Technology
IPS
Aspect Ratio
16:9
Brightness (Typ., cd/m²)
390 nit (w/o Glass, Typ.)
Contrast Ratio
1,200:1
Viewing Angle (H x V)
178 x 178
Response Time
8 ms (G to G)
Life Time (Min.)
30,000 Hrs (Min.)
Operation Hours (Hours / Day)
16Hrs/7 Days
Orientation
Landscape
Native Resolution
3,840 x 2,160 (UHD)
(Input) Video / Audio
HDMI (3), HDCP2.2/1.4
(Output) Video / Audio
Audio Out / Optical Output
(Input) USB
USB 3.0 Type A (3), USB 2.0 Type A (3)
(Input) External Control
RS-232C In (1)
Bezel Color
Black
Bezel Width
18.9/18.9/18.9/45.7 mm (T/R/L/B)
Weight (Head)
53.1Kg
Packed Weight
69.85Kg
Monitor Dimension (W × H × D)
1,710 × 1,020 × 87 mm
Handle
Yes
VESA™ Standard Mount Interface
800 x 400
Operation Temperature
0 °C to 40 °C
Operation Humidity
10 % to 80 %
Power Supply
AC 100-240 V~, 50 / 60 Hz
Power Type
Built-In Power
Power Consumption (Typ. / Max.)
260W / 350W
Safety
CB / NRTL
EMC
FCC Class "A" / CE / KC
ErP
Yes
Basic
Power Cord 3m, USB Cable (Type A-Type B) 5m, HDMI Cable 3m, Writing Pen (2pcs), User Manual, Quick Start Guide, Carton Box, Remote Controller (include battery 2ea), WiFi module
OPS type compatible
Yes (Slot)
OPS Power Built In
Yes
Speaker
Yes (10W x 2)
Available object size for touch
Ø3 mm ↑
Response Time
60ms ↓ (Android)
Accuracy
±2mm
Interface
USB 2.0
Protection Glass Thickness
4T (Anti-Glare)
Protection Glass Transmission
87%
Operating System Support
Windows 7/8/10 / Windows XP / Linux / Mac / Android (Supports one point touch on Windows XP / Linux / Mac)
Multi Touch Point
Max 20 Points
